| Hardware |
| Dimensions (mm) |
110 mm x 172 mm x 21 mm (4.3” x 6.8” x 0.8”) |
| Weight |
400g (14 Oz) |
| Display |
Color LCD TFT 7" (17,7 cm) 16:9 Format. 4.75" x 7" x 1.5" |
| Display Colors |
64 k |
| Display resolution |
800 x 480 pixels |
| Automatic brightness control |
YES |
| Keyboard |
10 hard keys, including a configurable key |
| Joystick |
Progressive Joystick + smart wheel selector |
| GPS Receiver |
u-blox 5 high sensitivity with WAAS position accuracy |
| Processor |
Freescale IMX515 800 MHz |
| RAM |
256 MB |
| Memory Support |
Micro SD preloaded with software and maps |
| Battery |
Removable, rechargeable lithium-Ion |
| Consumption |
max 10 Watt |
| Power supply |
Charger 10/35 V DC |
| Built-in Speaker |
YES |
| USB OTG master / slave |
YES |
|
Docking station
(optional extra) |
For panel mount. with 2 serial ports and 1 USB OTG, audio video input and audio output |
| Software |
|
Software update
(Operating System ) |
Free |
| 2D view |
YES |
Land Elevation (color coded topographic map showing the altitude of the terrain) |
Yes |
| Horizontal or Vertical mode |
YES |
| Full QWERTY virtual Keyboard |
YES |
| Fully customizable displa |
Choose what to see and where! TAWS, vertical profile, nav data, HIS, EFIS (GPS based). |
| Full flight planning capability |
Yes, up to 15 flight plans of up to 100 legs each |
| Vertical Profile on map |
YES |
Import and export flight plans, waypoints and routes from Navigator to PC |
Yes, with several third parties softwares |
| Editable aircraft checklist |
YES |
| Trip computer |
YES |
| Full simulator functions |
YES |
| TAWS - Terrain Awareness and Warning System |
YES |
| Integration with other on board navigation systems |
Yes: Autopilot, GPS, external antenna etc |
| Full or split HSI / RMI screen with data fields |
YES |
| Vertical navigation |
YES |
| Crossed Airspace predictor and advisor |
Get a preview of the airspaces that you will cross along your flight, and real time warnings on airspaces being crossed. |
| Real Time Traffic |
When connected with the Zaon XRX |
| Exchange data with Google earth |
Exchange Waypoints, FlightPlans and Tracks data between the navigator and Google Earth™ |
| Photo Database Creator |
Load your pictures up to fullscreen size on the navigator and assign them to an airport |
| Customizable Aircraft PROFILES |
Set a profile for each aircraft with different TAWS settings, selective displays etc. |
| Integration with other on-board devices |
EFIS, autopilot, external antenna, WXXM, CAS |
| Compatible with AvMap INCAS BB |
YES |
| Maps |
| Maps preloaded |
Europe - Africa |
| Worldwide Background |
YES |
| Jeppesen |
YES |
| Terrestrial background (NAVTEQ) |
YES |
| Street Maps (NAVTEQ) |
Europe |
| Low Airways (Victor Airways) |
YES |
| Avioportolano |
YES |
| Obstacles data |
YES |
| Airfields and Helipads |
More than 1300 unlicensed airfields and 1000 helipads for all Europe |
| Airport Diagram for taxi navigation |
YES |
| Approach plates |
YES |
