The aera 795 features 3D Vision, a unique 3D view of database-generated terrain. 3D Vision uses GPS position and the terrain-alerting database to recreate a behind-the-aircraft perspective view of the topographic landscape. The resulting virtual reality display offers pilots a supplemental 3D depiction of land and water features including terrain, obstacles, runways and airport signposts all shown in relative proximity to the aircraft. With the flick of a finger, the 3D view can be rotated around the aircraft to easily view the surrounding terrain. Using forward-looking terrain avoidance capability, the aera 795 predicts in advance where potential hazards may exist and colorises the landscape showing amber or red overlays on those areas. Any towers or obstacles that may encroach upon the flight path are color-highlighted and clearly displayed with height-appropriate symbology.
The path to a paperless cockpit
For pilots who prefer Jeppesen charts and diagrams, Garmin also offers a ChartView enablement option. Garmin ChartView utilizes Jeppesen’s extensive library to provide global charting capabilities.
Other new features include a built-in digital document viewer that enables the pilot to load and view PDF documents, JPEG photos, and many other electronically formatted materials including checklists and detailed performance/procedural data from the aircraft flight manual. There is also a convenient scratch pad for writing down clearances or other important notes.
Added support for helicopter missions
The addition of optional City Navigator data on the aera 795 allows the user to search and locate any desired surface address for use as a flight plan waypoint or for aerial direct-to navigation. This makes it even easier for helicopter and fixed-wing operators to respond to critical missions around streets and highways, survey land or perform search and rescue operations.
Instrument back up and traffic
Garmin’s patented Panel Page on the aera 795 offers a backup solution to the instrument panel with its exclusive display of GPS-derived panel information, including track indication, GPS altitude, groundspeed, vertical speed and turn indication. Plus, the internal GPS provides position updates five times per second (5 Hz), allowing it to present flight data more smoothly and accurately.
The aera 795 will also display traffic if coupled to a compatible traffic source like the Zaon XRX. Garmin has increased the interface capability through the addition of a second serial port to allow even more connectivity simultaneously. With two serial ports, the pilot can display traffic information, send frequencies to a Garmin SL30 or SL40 radio, send position information and more to other select aircraft devices.
Airport Directory and more
Pilots can enjoy the AC-U-KWIK airport directory database, which features worldwide airport information for more than 7,800 airports globally, and contains hard-to-find information for pre-flight planning in North America, Europe, Asia, Central America, the Caribbean, South America, Africa and Australia.
The aera 795 Atlantic is pre-loaded with VFR reporting points (VRPs), AC-U-KWIK international airport directory data and obstacles where available.
